Ubiquiti UniFi Gateway Fiber 10G Gateway Router with 2.5 GBE Switch - UXG-FIBER

Description

The Ubiquiti UXG-Fiber is a high-performance, independent 10G gateway designed for network administrators who need advanced routing, security, and control without a built-in controller. It is ideal for businesses and power users requiring high-speed connectivity and enterprise-grade threat management, and is managed via an external UniFi Network Server, CloudKey, or Official UniFi Hosting.

Key Features & Description
    High-Speed Connectivity: The gateway supports up to 5 Gbps IDS/IPS routing throughput and features dual 10G WAN ports (one SFP+ and one RJ45) for flexible, high-bandwidth internet connections.
    Integrated Switching with PoE+: It includes an integrated 4-port 2.5 GbE RJ45 switch, with one port offering 30W PoE+ to power compatible devices like access points or VoIP phones directly.
    Advanced Security: The UXG-Fiber provides a comprehensive suite of security features, including a stateful firewall, application-aware Layer 7 filtering, Deep Packet Inspection (DPI), content filtering, ad blocking, and signature-based Intrusion Detection and Prevention Systems (IDS/IPS).
    Versatile VPN & Networking: It supports various VPN protocols (WireGuard, IPsec, OpenVPN, L2TP, Teleport zero-config VPN), multi-WAN load balancing, dynamic routing (OSPF), and advanced QoS to ensure reliable and secure connections.
    Compact Form Factor: The device features a sleek, compact desktop design, making it suitable for small businesses and home networks where space is a consideration.

Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server
5 Gbps routing with IDS/IPS
(1) 10G SFP+ and (1) 10 GbE RJ45 WAN port
(1) 10G SFP+ LAN port
Integrated 4-port switch with (1) PoE+ port

Dimensions 212.8 x 127.6 x 30 mm (8.4 x 5 x 1.2″)
Default WAN Ports (1) 10G SFP+ / (1) 10 GbE RJ45
LAN Ports (1) 10G SFP+ / (4) 2.5 GbE RJ45
IDS/IPS Throughput 5 Gbps
Form Factor Compact desktop
Stateful Firewall Yes
Application-Aware Layer 7 Firewall Yes
DPI and Traffic Identification Yes
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) Yes
Content Filtering Yes
Intrusion Prevention (IPS/IDS) Yes
Ad Blocking Yes
IDS/IPS Signatures 55,000+ With CyberSecure
License-Free SD-WAN Yes
Site to Site VPN  / Site Magic / Yes
IPsec Yes
OpenVPN Yes
VPN Server Teleport Zero-Configuration VPN Yes
WireGuard Yes
OpenVPN Yes
L2TP Yes
VPN Client OpenVPN / Yes
WireGuard Yes
Multi-WAN Load Balancing Yes
Dynamic Routing – OSPF Yes
Advanced QoS Yes
Multicast DNS (mDNS) Yes
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) Yes
Integrated RADIUS Server Yes
RADIUS over TLS (RadSec) Yes
Additional Internet Failover with UniFi LTE Backup Yes
Internet Quality and Outage Reporting Yes
MAC Address Table Size 4000
PoE Budget 30W
Voltage Range PoE Mode 50—57V
Max. Power Consumption 25W (Excluding PoE output)
Power Method DC jack (54V DC/1.1A)
Power Supply 54V DC/1.1A (Adapter included)
Supported Voltage Range 100—240V AC
Processor Quad-core ARM Cortex-A73 at 2.2 GHz
System Memory 2 GB
Weight 605 g (1.3 lb)
Enclosure Material Polycarbonate
Management Ethernet / Bluetooth
System LEDs Ethernet/ SFP+ / System
Certifications CE, FCC, IC
